Plots of hazdata objects.

Baseline hazards estimates.

# S3 method for logrank
plot(
  x,
  fn = c("cum", "surv", "log", "loglog"),
  xlim = NULL,
  ylim = NULL,
  main = NULL,
  xlab = "",
  ylab = "",
  col = "black",
  lty = 1,
  printLegend = TRUE,
  ...
)

Arguments

x	A logrank object, typically the 'hazards' element in the output from link{logrank}.
fn	Which type of plot? Allowed values are "cum" (or "cumhaz"), "surv" (or "sur"), "log", or "loglog". The last two plots the cumulative hazards on a log (y) scale or a log-log (xy) scale, respectively.
xlim	Horizontal plot limits. If NULL, calculated by the function.
ylim	Vertical plot limits. If NULL, set to c(0, 1) for a plot of the survival function.
main	A heading for the plot.
xlab	Label on the x axis.
ylab	Label on the y-axis.
col	Color of the lines. May be a vector of length equal to No. of strata.
lty	Line type(s). May be a vector of length equal to No. of strata.
printLegend	Logical or character; should a legend be produced? Defaults to TRUE. If character, it should be one of bottomleft, bottomright, etc, see legend.
...	Anything that plot.default likes...

Value

A list where the elements are two-column matrices, one for each stratum in the model. The first column contains risktimes, and the second the y coordinates for the requested curve(s).

Details

It is also possible to have as first argument an object of type "coxreg", given that it contains a component of type "hazdata".

Note

x is a list where each element is a two-column matrix. The first column contains failure times, and the second column contains the corresponding 'hazard atoms'.

Author

Göran Broström

Examples

fit <- logrank(Surv(enter, exit, event), group = civ, data = oldmort)
plot(fit)
